Nylon Cage Needle Roller Clutch Bearing 8482102000 NK15 12 For Machine Tool

Ask Lasest Price
Brand Name :	NEKIB OR FUMSB
Model Number :	NK15/12
Certification :	ISO9001,IATF16949
Price :	0.1-100$ one piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	300kpcs,30days
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

Nylon Cage Needle Roller Clutch Bearing 8482102000 NK15 12 For Machine Tool

High precision Open Seal Steel needle roller bearing without shoulder with inner ring/NK15/12

Description:

The needle roller bearing without inner ring is suitable for the parts of which the radial size is limited.Because of no inner ring, the surface of shaft journal fitted with it is acted directly as rolling surface. It is requested that the surface hardness be no less than HRC60, surface roughness, no more than 0.63um. This kind of bearing does not limit the axial shift of shaft and housing and has high limiting rotational speed.

Because of no inner ring, this needle roller bearing is suitable for parts of which the radial size is limited.The surface of shaft journal fitted with it is acted directly as rolling surface. lt is requested that the surface hardness of shaft journal be no less than HRC60 and the surface roughness Ra value, no more than 0.63hm.This kind of bearing does not limit the axial shift of shaft and housing .

Application:

NK 15/12 needle roller bearing for textile machinery .

Drawings:

No inner ring solid ferrule needle bearing RNA NK series

Product Name	Needle Roller Bearing
Precision Rating	P6, P0, P5, P4, P2
Material	Bearing Steel (GCr15)
Clearance	C0 C1 C2 C3 C4 C5
Vibration & Noisy	Z1,Z2,Z3 V1,V2,V3
Features	High Precision, High Speed, Long Life, High Reliability, Low Noise , Reduce Friction
Certification	ISO 9001:2008;IATF16949
Packing	1.Neutral Packing Bearing 2.Industrial Packing 3.Commercial Packing Bearing 4.Customize
Delivery Time	30 - 45 Days After The Order is Confirmed
Shippment	1.By Sea 2.By Air 3.By Express
Website	http://www.fums-bearing.com

Shaft diameter	Model	Boundary Dimensions				Basic load rating		Limiting speed
		FW	D	C	rS	dynamic	static	oil

						C	Co
mm		mm			Min.	N		rpm
85	NK 85/25	85	105	25	1	69000	123000	5500
	NK 85/35	85	105	35	1	98000	193000	5500
	RNA4915	85	105	30	1	86000	162000	5500
	RNA6915	85	105	54	1	130000	275000	5500
90	NK 90/25	90	110	25	1	72000	132000	5000
	NK 90/35	90	110	35	1	103000	208000	5000
	RNA4916	90	110	30	1	89000	174000	5000
	RNA6916	90	110	54	1	135000	300000	5000
95	NK 95/26	95	115	26	1	73000	137000	4800
	NK 95/36	95	115	36	1	107000	223000	4800
100	NK 100/26	100	120	26	1	76000	146000	4600
	NK 100/36	100	120	36	1	111000	237000	4600
	RNA 4917	100	120	35	1.1	111000	237000	4600
	RNA 6917	100	120	63	1.1	166000	400000	4600
105	NK 105/26	105	125	26	1	78000	155000	4400
	NK 105/36	105	125	36	1	114000	250000	4400
	RNA 4918	105	125	35	1.1	114000	250000	4400
	RNA6918	105	125	63	1.1	172000	425000	4400
110	NK 110/30	110	130	30	1.1	98000	210000	4200
	NK 110/40	110	130	40	1.1	127000	290000	4200
	RNA 4919	110	130	35	1.1	116000	260000	4200
	RNA 6919	110	130	63	1.1	174000	440000	4200
115	NKS 115	115	135	32	1.1	91000	204000	4000
	RNA 4920	115	140	40	1.1	128000	270000	4000
120	NK 120/40	120	140	40	1.1	113000	275000	3900
	RNA 4822*)	120	140	30	1	94000	216000	3900
125	RNA 4922*)	125	150	40	1.1	132000	290000	3700
130	RNA 4824*)	130	150	30	1	99000	239000	3600
135	RNA 4924*)	135	165	45	1.1	181000	390000	3400
145	RNA 4826*)	145	165	35	1.1	118000	310000	3200
150	RNA 4926*)	150	180	50	1.5	203000	470000	3100
155	NK 155/32	155	180	32	1.5	114000	260000	3000
	RNA 4828*)	155	175	35	1.1	120000	325000	3000
160	RNA 4928*)	160	190	50	1.5	209000	500000	2900
165	RNA 4830*)	165	190	40	1.1	152000	400000	2800
175	RNA 4832*)	175	200	40	1.1	160000	435000	2700
185	RNA 4834	185	215	45	1.12	185000	510000	2500
195	RNA 4836*)	195	225	45	1.1	194000	550000	2400
210	RNA 4838	210	240	50	1.5	227000	690000	2300
220	RNA 4840*)	220	250	50	1.5	230000	720000	2200
240	RNA 4844*)	240	270	50	1.5	243000	790000	2000
265	RNA 4848*)	265	300	60	2	355000	1080000	1800
285	RNA 4852*)	285	320	60	2	370000	1160000	1700
305	RNA 4856*)	305	350	69	2	450000	1300000	1500
330	RNA 4860*)	330	380	80	2.1	620000	1770000	1400
350	RNA 4864	350	400	80	2.1	630000	1850000	1300
370	RNA 4868	370	420	80	2.1	640000	1940000	1300
390	RNA 4872	390	440	80	2.1	660000	2020000	1200
415	RNA 4876	415	480	100	2.1	1000000	2900000	1100

and so on
