P4 Double Row Full Complement Cylindrical Roller Bearings CPM2815 In Stock

Ask Lasest Price
Brand Name :	NEKIB OR FUMSB
Model Number :	SL 04 series
Certification :	ISO9001,IATF16949
Price :	0.1-100$ one piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	300kpcs,30days
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

P4 Double Row Full Complement Cylindrical Roller Bearings CPM2815 In Stock

Mechanical Parts Spherical full complement roller bearing/Double Row/With Seal

Products introduction:

Full complement cylindrical roller bearings have solid inner and outer rings and rib-guided cylindrical rollers. Since these bearings have the largest possible number of rolling elements, they have extremely high radial load carrying capacity, high rigidity and are suitable for particularly compact designs.

Due to their kinematic conditions, however, they cannot achieve the high speeds that are possible when using cylindrical roller bearings with cage.

SL04 50..PP,SL04..PP ect.

Drawings and parts of models:

Feature:

Product Name	Spherical Roller Bearing
Precision Rating	P6, P0, P5, P4, P2
Material	Bearing Steel (GCr15)
Clearance	C0 C1 C2 C3 C4 C5
Vibration & Noisy	Z1,Z2,Z3 V1,V2,V3
Cage	Brass, Nylon, Steel
Seal	ZZ, 2RS
Features	High Precision, High Speed, Long Life, High Reliability, Low Noise , Reduce Friction
Certification	ISO 9001:2008
Packing	1.Neutral Packing Bearing 2.Industrial Packing 3.Commercial Packing Bearing 4.Customize
Delivery Time	30 - 45 Days After The Order is Confirmed
Shippment	1.By Sea 2.By Air 3.By Express

Double-row full complement roller bearing parameters:

							(r/min)* Limiting speed

Dimension					(kN)				Bearing code

					Rated load			(Kg)

								Weight
				rs

d	D	C	B	min	Cr	Cor			FUMS	INA
20	42	29	30	0.3	40.2	52	3600	0.21	NNF5004-2LSNVY	SL045004ppx
25	47	29	30	0.3	44.6	62	3000	0.23	NNF5005-2LSNVY	SL045005ppx
30	55	33	34	0.3	52.8	75	2600	0.35	NNF5006-2LSNVY	SL045006ppx
35	62	35	36	0.3	66	91.5	2200	0.45	NNF5007-2LSNVY	SL045007ppx
40	68	37	38	0.6	79	116	2000	0.53	NNF5008-2LSNVY	SL045008ppx
45	75	39	40	0.6	95	146	1880	0.68	NNF5009-2LSNVY	SL045009ppx
50	80	39	40	0.6	101	160	1700	0.73	NNF5010-2LSNVY	SL045010ppx
55	90	45	46	0.6	119	193	1500	1.1	NNF5011-2LSNVY	SL045011ppx
60	95	45	46	0.6	123	208	1400	1.2	NNF5012-2LSNVY	SL045012ppx
65	100	45	46	0.6	128	224	1300	1.3	NNF5013-2LSNVY	SL045013ppx
70	110	53	54	0.6	190	325	1200	1.85	NNF5014-2LSNVY	SL045014ppx
75	115	53	54	0.6	201	355	1100	2	NNF5015-2LSNVY	SL045015ppx
80	125	59	60	0.6	233	415	1000	2.7	NNF5016-2LSNVY	SL045016ppx
85	130	59	60	0.6	251	430	1000	2.75	NNF5017-2LSNVY	SL045017ppx
90	140	66	67	0.6	297	550	900	3.8	NNF5018-2LSNVY	SL045018ppx
95	145	66	67	0.6	303	570	900	3.95	NNF5019-2LSNVY	SL045019PPX
100	150	66	67	0.6	308	570	850	4.05	NNF5020-2LSNVY	SL045020PPX
110	170	79	80	0.6	380	695	750	6.45	NNF5022-2LSNVY	SL045022PPX
120	180	79	80	0.6	402	750	700	6.9	NNF5024-2LSNVY	SL045024PPX
130	200	94	95	0.6	572	1040	630	10.5	NNF5026-2LSNVY	SL045026PPX
140	210	94	95	0.6	594	1120	600	11	NNF5028-2LSNVY	SL045028PPX
150	225	99	100	0.6	693	1290	560	13.5	NNF5030-2LSNVY	SL045030PPX
160	240	108	109	0.6	721	1400	500	16.5	NNF5032-2LSNVY	SL045032PPX
170	260	121	122	0.6	935	1800	480	22.5	NNF5034-2LSNVY	SL045034PPX
180	280	135	136	0.6	1080	2120	450	30	NNF5036-2LSNVY	SL045036PPX
190	290	135	136	0.6	1100	2200	430	31.5	NNF5038-2LSNVY	SL045038PPX
200	310	149	150	0.6	1340	2900	400	42	NNF5040-2LSNVY	SL045040PPX
220	340	159	160	1	1510	3100	360	53.5	NNF5044-2LSNVY	SL045044PPX
240	360	159	160	1	1570	3350	340	57.5	NNF5048-2LSNVY	SL045048PPX

and so on.
