Low Noise Full Complement Cylindrical Roller Bearings High Strength Cage

Ask Lasest Price
Brand Name :	NEKIB OR FUMSB
Model Number :	SL04-5034nr
Certification :	ISO9001,IATF16949
Price :	0.1-100$ one piece
Payment Terms :	L/C, D/A, D/P, T/T, Western Union, MoneyGram
Supply Ability :	300kpcs,30days
Delivery Time :	5-8 work days

Add to Cart

Product Details
Company Profile

Low Noise Full Complement Cylindrical Roller Bearings High Strength Cage

High precision/ Single-row full cylindrical roller bearings,bearing steel/without cage/SL08 series/for industrial application

Product description:

Full complement cylindrical roller bearings to withstand heavy loads and design. In the same breadth, the bearings and traditional bearings with cage, compared with a high load carrying capacity, small radial section, you can save space, but the speed is relatively low. To make bearing work, in the case of continuous operation, the bearings must bear a certain minimum load, ie, C / P <25. Otherwise it will aggravate frayed due to insufficient lubrication and high-speed operation. All multi-row cylindrical roller bearings in the outer ring has a lubrication groove and lubrication holes.

Drawings:

Parameters of single-row full complement cylindrical roller bearing:

Dimension(mm)				Rated load(kN)		Limiting		Bearing code

						speed	Weight(Kg)
			rs					FUMS

d	D	B	min	Cr	Cor				INA
	42	16	0.6	27.5	26.5	9000	0.11	NCF3004V	SL183004

20
	47	18	1	41	37.5	7000	0.16	NCF2204V	SL182204
	47	16	0.6	31.5	32.5	7500	0.12	NCF3005V	SL183005
25



	52	18	1	46	45	6000	0.18	NCF2205V	SL182205
	62	24	1.1	63	57	4500	0.37	NJ2305V	SL192305
	55	19	1	40.5	43	6500	0.2	NCF3006V	SL183006



30
	62	20	1	61	63	5000	0.3	NCF2206V	SL182206
	72	27	1.1	87	85	3800	0.56	NJ2306V	SL192306
	62	20	1	49.5	55	5500	0.26	NCF3007V	SL183007



35
	72	23	1.1	76	77	4300	0.44	NCF2207V	SL182207
	80	31	1.5	113	112	3400	0.74	NJ2307V	SL192307
	68	21	1	59	68	5000	0.31	NCF3008V	SL183008



40
	80	23	1.1	84	89	3800	0.55	NCF2208V	SL182208
	90	33	1.5	152	155	3000	1.01	NJ2308V	SL192308
	75	23	1	63	76	4600	0.4	NCF3009V	SL183009



45
	85	23	1.1	88	96	3600	0.59	NCF2209V	SL182209
	100	36	1.5	162	165	2700	1.37	NJ2309V	SL192309
	80	23	1	77	92	4300	0.43	NCF3010V	SL183010



50
	90	23	1.1	95	109	3300	0.64	NCF2210V	SL182210
	110	40	2	205	215	2500	1.81	NJ2310V	SL192310
	90	26	1.1	105	134	3700	0.64	NCF3011V	SL183011



55

and so on.

Product pictures:
